Raspberry Pi 5th Generation. More powerful than ever Single Board Computer.

  Raspberry – what is your association?

  Cute and aromatic little fruit – Yes Of Course.

  But, If We add a PI extension!

or Raspberry PI –

  Now, It can be said that it is compact but powerful, nice to implement in almost any kind of attractive design, and a favorite for many DIY enthusiasts on single-board PCs.

  Yes, It is one of the best single-board Computer Hardware platforms.



Introducing RASPBERRY PI 5th Generation



  We have been wanting about 5 years between today and the last bestselling version – RPI4.

  The 5th Version, which as it looks is the most attractive, uses the most powerful hardware implemented until now.

  Now, we will structure a list with the main benefits of today’s described device.



Raspberry PI 5 Key Features:

  • Central Processing Unit (CPU)
    • 2.4GHz quad-core 64-bit Arm Cortex-A76
    • 512 KB of Memory for each core L2 Cache
    • 2MB of shared Memory for L3 Cache
  • Graphics Processing Unit (GPU)
    • VideoCore VII GPU,
    • Supporting OpenGL ES 3.1, Vulkan 1.2
  • Dual 4K/60fps HDMI® display output
  • 4K/60fps HEVC decoder
  • RAM Memory
    • LPDDR4X-4267 SDRAM – 4GB and 8GB SKUs variants are available
  • Connectivity
    • Dual-band 802.11ac Wi-Fi®
    • Bluetooth 5.0 / Bluetooth Low Energy (BLE)
    • 2 × USB 3.0 ports, supporting simultaneous 5Gbps operation
    • 2 × USB 2.0 ports
    • Gigabit Ethernet, with PoE+ support (requires separate PoE+ HAT, coming soon)
    • 2 × 4-lane MIPI camera/display transceivers
    • PCIe 2.0 x1 interface for fast peripherals
    • Raspberry Pi standard 40-pin GPIO header for the all-new custom GPIO Chip
  • External Memory
    • High-speed microSD card interface with SDR104 mode support
  • Real-time clock backed up with an external battery
  • Power button



Let’s see the Introducing Video:



VIDEO. 1   Eben Upton introduces Raspberry Pi 5



Part Technical Specification
CPU

Broadcom BCM2712 2.4GHz quad-core 64-bit Arm Cortex-A76

cryptography extensions,

512KB per-core L2 caches and a 2MB shared L3 cache

GPU VideoCore VII GPU supporting OpenGL  ES 3.1,  Vulkan 1.2
Display Output Dual 4K/60fps HDMI® display output with HDR support
Video Decoder 4K/60fps HEVC decoder
Memory LPDDR4X-4267 SDRAM (4GB and 8GB SKUs available at launch)
Wireless Connectivity

2.4 GHz & 5 GHz 802.11ac Wi-Fi,

Bluetooth 5.0 / Bluetooth Low Energy (BLE)

Storage microSD card slot with support for high-speed SDR104 mode
USB Ports

2 × USB 3.0 Ports supporting simultaneous 5Gbps operation,

2 × USB 2.0 ports

Ethernet Gigabit Ethernet with PoE+ support (requires separate PoE+ HAT)
Camera/Display Interfaces 2 × 4-lane MIPI camera/display transceivers
Peripheral Interface PCIe 2.0 x1 interface for fast peripherals (requires separate M.2 HAT or other adapter)
Power Supply 5V/5A DC power via USB-C with Power Delivery support
GP I/O Header Raspberry Pi standard 40-pin header
Real-time Clock (RTC) Using an external Backup battery
Power Button Included

TABLE.



  Last, but not least is the price.

  There were expectations about increasing the value, logically because of enhancements in performance and great updates of technical parameters.

  The exact recommended prices for the Pi 5, as stated by the Raspberry Pi Foundation itself, are:

  • Raspberry Pi 5 (4 GB variant) – 60 USD
  • Raspberry Pi 5 (8 GB variant) – 80 USD

  Previous version – Raspberry Pi 4 is priced at 55 USD for the 4 GB variant and 75 USD for the 8 GB variant

  As we can remember, e.g. the reveal of the Raspberry Pi 1B, was with a starting price of 35 USD.



  Where You can buy the Raspberry Pi 5?

  In The U.S.

Link to All Variants – scope “Raspberry Pi 5”  at Amazon.com

or

Check the 8GB Variant and Prices at Amazon.com

Check the 4GB Variant and Prices at Amazon.com



  In the UK

Check the 4GB Variant and Prices at Amazon.Co.UK



Let this Perfect compact product inspire you

for your next hardware project – that is sure to impact the World!
